Powering the CopperHead 3400 Base Station
Powering the CopperHead 3430AP Camera Unit
Base Station Main Power 1 Turn on the Base Station Power Mains Switch located at the
rear left (when facing the back of the Base Station) #3 on the
overall diagram. This switch is only on Base Station units with
internal power. The front panel power light will come on and be
red until the next step.
Base Station Power 2 Turn on the Front Panel Power Switch located at the front
right. #15 on the overall diagram. The power monitor indicator
turns from red to green.
Four Character Display
LED Indicator
progression 3 The 4 character display indicates TEST and all front panel
LEDs turn red, then green, then orange, then off.
REV display 4 The LED color test is followed by REV and the revision of
the display microcontroller firmware.
Scrolling 5 The REV indication is followed by “miranda.com” scrolling
across the 4 character display. If there's no scrolling, please
contact Grass Valley - A Belden Brand support for assistance.
PAUSE 6 The scroll is followed by about a 3 second interval used to
synchronize all the microcontrollers in the base station
Diagnostics 7 The front panel will cycle through the diagnostics displays –
See Section 6.5
Current Status Displayed 8 After the 3 second pause, all the front panel displays update
with current status. If the Camera Unit is not powered on
the camera- related status lights will show red.
Camera Unit power 1 Turn on the camera unit power switch
Camera Power 2 Turn on the camera power.
Four Character Display LED
Indicator progression 3 On power-on, the four character display indicates the
current Revision Version (REVA). Your unit will reflect the
current Revision Version. After the revision display the cur-
rent Fiber Link strength is displayed. A typical display is 0 to
‐27. This indicates Fiber link strength of from 0 to ‐27 dBm.
