54 8943FC — Instruction Manual
Specifications
Environmental
Frame temperature range
Refer to GeckoFlex Frames 8900FX/FF/FFN Signal Processing Systems Instruction Manual
at
www.grassvalley.com/docs/modular
Operating humidity range
Non-operating temperature
Power
Power consumption 7.5 Watts with two SFP devices
Table 7. Optional Receiver/Transceiver Fiber Optic SFP Device Specifications
Model Numbers
SFP-13103G-M1DRX-K
SFP-13103G-M1DRX,
SFP-13103G-M2DRX
SFP-13103G-M1TRX-K
SFP-13103G-M1TRX
SFP-13103G-M2TRX
Low wavelength 1270nm 1270nm
High wavelength 1610nm 1610nm
Receiver channels 2 1
Connector type LC
Fiber support Single-mode
Data rate 143 Mb/s to 2.97 Gb/s
Maximum Receive Signal Levels @ 2.97 Gb/s,
360 Mb/s, and 270 Mb/s -3 dBm
(0.501 mW)
Minimum Receive Signal Levels @ 2.97 Gb/s,
360 Mb/s, and 270 Mb/s - 23 dBm
(0.500794 mW)
Table 6. 8943FC Specifications
Parameter Value
