1-34
e Figure 1-23 Specify a user profile nam
3) Verify the configuration
The AP group applied in the user profile contains only AP 1, and thus a client can only access the WLAN
through AP 1.
AP Group Configuration for Inter-AC Roaming
Network requirements
As shown in the figure below, AC1 and AC2 belong to the same mobility group. Configure an AP group
on the ACs so that a client can still access the WLAN when it moves from between APs.
Figure 1-24 AP group configuration for inter-AC roaming
Configuration procedure
Configuration on the RADIUS server is similar with that in AP Group Configuration without Roaming and
thus is omitted.
1) Configuration on AC 1
# Configure AP 1.
