LBI-39224
4-22
Figure 55 GSC Node Statistics Dialog Box
Press the F1 key to access the Help function.
Clear Data
Choose the Clear Data button to reset the data display and allow a
refresh of the display. All counts are from the last reset.
Close
Choose the Close button to exit the NODE STATISTICS dialog box
and return to the Active Devices dialog box.
Last Cleared
Displays the time and date of the last
Clear Data command.
GSC ID
Displays the current hexadecimal GSC address.
Type
Displays the interface module type: MIM, MOM, etc.
Assign
Displays the setting of the interface module's Controller Board dip
switches (site assignment number).
Errors
Displays the number of errors currently existing that affect the selected
interface module. This count will include errors that affect only the
current interface module plus the number of global system errors. In
some cases the sum of all the values displayed in this field for each
