Figure 17. Full Matrix Sign Assembly—Horizontal Orientation—With Rails for
Two Odd and One Even Rows
SBC
Power and Communication connectors (not shown)
Figure 18. Full Matrix Sign Assembly—Vertical Orientation—One Odd/One Even Row
Left Jumper BRICK Assembly Trim BRICK
Figure 19. Full Matrix Sign, 4 × 3—Horizontal Orientation—Completed
