Instructions Revision
11/14/07
Contact your nearest Airaid dealer for an Airaid Intake
The sound of power...The “whistle” means its working!
3. Using a 10mm socket, remove three factory
bolts, and one nut. Pull the throttle body towards
the radiator until it clears the stud, and then move
it aside. 4. Using a stud remover or pair of pliers, carefully
remove the factory stud from the intake manifold.
5. Position the Poweraid Spacer (#1) and gasket
(#2) between the throttle body and intake mani-
fold. Insert four 6mm x 65mm hex bolts (#3), and
6mm flat washers (#4) thru the throttle body, gas-
ket, Poweraid Spacer, and into the intake manifold.
Using a 10mm socket, tighten all four throttle body
bolts evenly, to the manufacturers specifications.
Do Not Over Tighten The Bolts! 6. Re-install the intake tube and engine beauty
cover. Reconnect the negative battery cable!
Nut
Poweraid
Spacer
Gasket
6mm Bolts
and
Washers
