Airaid 400-633 - Manual

Parts List
#1 Poweraid Spacer x1
#2 Gasket x1
#3 6mm x 75mm Hex Bolts x4
#4 6mm Flat Washers x4
Tools Required For Installation
5/16”, 10mm Sockets
Ratchet & Extension
Installation Instructions
Part Number 400-633
Poweraid Spacer For
2009-10 Ford F-150
4.6L 3-V
Thank you for purchasing the Poweraid Throttle Body Spacer. Please read the in-
struction manual carefully before proceeding with the installation. Contact AIRAID @ (800)
498-6951 8:00 AM - 5:00 PM MST Weekdays for questions regarding fit or instructions that
are not clear to you. Your Poweraid Throttle Body Spacer was carefully inspected and
packaged. Check that no parts are missing, or were damaged during shipping. If any
parts are missing, please contact AIRAID.
Thank you for selecting AIRAID.
1. Disconnect the negative battery cable!
Disconnect the crankcase breather hose from the
engine air intake tube by pushing on the green tab,
and removing the hose from the nipple. Loosen the
hose clamp that secures the intake tube to the throt-
tle body, and the one that secures the intake tube to
the airbox lid. Remove the intake tube and set aside
for now. 2. Remove the four bolts from the throttle body, and
remove the throttle body from the intake manifold,
and set it aside. There’s no need to disconnect the
wiring harness.
