Installation Instructions. Read Me!
1. DISCONNECT NEGATIVE (-) BATTERY CABLE.
2. Remove throttle body intake assembly.
3. Remove (4) bolts from the throttle body. (Ref. “C”)
4. Install the power plate using (2) gaskets. (Ref. “A” & “B”)
A. Place one gasket between the throttle body and power plate.
B. Place second gasket between the power plate and manifold.
( On the 4.0L Mustang, use only one gasket between the throttle body and the Poweraid spacer.)
5. Install (4) 6mm x 70mm bolts and (4) 6mm washers using Step 3 as an example. (Ref. “C”)
6. Inspect & Test the throttle linkage for full Open & Closed travel before driving. Some cruise or kickdown
cables may require adjustment. Please refer to your vehicles service manual for proper adjustment.
7. Reinstall the throttle body intake assembly using Step 2 as an example.
8. Reconnect negative battery cable. Enjoy!
Rev. 10/10/06
Ref. “A”- Throttle Body
Ref. “B”- (1) Power Plate
(2) Gaskets
Ref. “C”- (4) 6mm x 70mm Bolts
(4) 6mm Washers
AIRAID Filter Co. 2688 E Rose Garden Ln. Phoenix AZ 85050 (800) 498-6951 [email protected] www.airaid.com
Included with your Poweraid Spacer is a sticker with a California Air Resources Board
(C.A.R.B.) Executive Order (EO) number. This sticker must be placed in plain view inside of
the engine compartment. Failure to do so may prevent you from passing a smog inspection.
