Instructions Revision
05/25/10
Contact your nearest Airaid dealer for an Airaid Intake
System for your car, truck or SUV.
The sound of power...The “whistle” means its working!
3. Install the O-Ring (#2) into the groove on the
Poweraid Spacer (#1). Install the spacer between the
intake manifold, and the throttle body with the O-
Ring facing the throttle body. Insert four 6mm x
60mm Hex Bolts (#3), and 6mm Flat Washers (#4)
through the throttle body, Poweraid Spacer, and into
the intake manifold. Using a 10mm socket, tighten
all 4 throttle body bolts evenly, to the manufac-
turer’s specifications.
Do Not Over Tighten The Bolts! 4. Reinstall the factory intake tube, and tighten the
hose clamp. Reconnect the Air temperature sensor
and throttle body motor. Re-connect the negative
battery cable!
Spacer
O-Ring
Throttle
Body
