Instructions Revision
03/05/12
Contact your nearest Airaid dealer for an Airaid Intake System
for your car, truck or SUV.
The sound of power...The “whistle” means its working!
3. Using a 10mm socket, remove the four bolts that
secure the throttle body to the intake manifold.
Next, rotate the factory throttle body out of the
way to allow access to the intake manifold. Make
sure the factory blue gasket is seated in the groove
on the intake manifold. 4. Install the Poweraid Spacer (#1) with the bore
extending into the intake manifold. Install the Gas-
ket (#2) between the Poweraid Spacer and the throt-
tle body. Install four 6mm x 50mm hex bolts (#3) and
6mm flat washers (#4) through the throttle body,
Poweraid Spacer, Gasket, and into the intake mani-
fold. Using a 10mm socket, tighten all four throttle
body bolts evenly, to the manufacturer’s specifica-
tions. Do Not Over Tighten The Bolts!
Poweraid Spacer
Gasket
Throttle Body
5. Re-install the factory intake tube or resonator onto the vehicle. Re-connect the factory temperature sensor wiring
harness. Tighten all hose clamps securely. Re-connect the negative battery cable!
6mm Hex Bolts
6mm Flat Washers
Included with your Poweraid Spacer is a sticker with a California Air Resources Board
(C.A.R.B.) Executive Order (EO) number. This sticker must be placed in plain view inside of
the engine compartment. Failure to do so may prevent you from passing a smog inspection.
Please Note: The 2010 Ram, Dakota, Nitro, and Liberty listed above are not included in the C.A.R.B. E.O.
number at this time. They are pending.
