69
Terminal : Mini DIN 8-PIN
SERVICE PORT CONNECTOR
R X D
-----
-----
GND
-----
-----
-----
1
2
3
4
5
6
7
8
COMPUTER IN 1 /COMPUTER IN 2 /COMPONENT IN /MONITOR OUT (ANALOG)
Terminal: Analog RGB (Mini D-sub 15 pin)
5 1 2 3 4
10 9 6 7 8
15 14 13 11 12
Configurations of Terminals
Red (R/Cr) Input/ R Output
Ground (Horiz.sync.)
Green (G/Y) Input/ G Output
-----
Blue (B/Cb) Input/ B Output
Ground (Red)
Ground (Green)
Ground (Blue)
1
5
2
4
3
6
7
8
+5V Power / ---
Horiz. sync. Input (Composite H/V sync.)
Ground (Vert.sync.)
DDC Data / ---
Ground
Vert. sync.
DDC Clock / ---
9
13
10
12
11
14
15
T X D
1 2
3 4 5
8 7 6
Appendix
Dimensions
10.3 (262)
13.15(334)
2.0(51.3)
3.17(80.5)
5.1(129.0) 5.2(132.0)
2.8(70.5)
5.1(129.0) 4.4(112.5)
5.5(140.0)
3.1(78) 3.6(91.3)
Unit: inch(mm)
Screw Holes for Ceiling Mount
Screw: M4
Depth: 0.472(12.0)
