Figure 11: SRC (30/60) Stainless Steel Vacuum Receiver Dimensions
Note: SRC60 Vacuum Receiver (shown)
( Mounting Flange -14” Diameter Cut-Out)
Model # Cu. ft. A C D E F H J K
3.0 47 39
SRC60 6.0 55
NA
42
16 6 20 NA 7
Metric Standards • Dimensions in cm
Model # Liters B
Dimensions (inches)
B G
SRC30 26
15
63
16” OD
K
J
A C D E F G H J K
SRC30 85 119 100 66
SRC60 170 159 140
N/A
106
41 15 51 N/A 38 19
5/16”/0.3125” (8.00 mm) -diameter holes, two (2) places equally spaced.
1/4”/0.2500” (6.35 mm) -diameter holes, six (6) places equally spaced; I is standard mounting hole location.
