Page 23
Range Leads Read Multiply
Switch Red Black Scale Divide / Direct
0.6 VDC VOM COM 0 - 60 Divide by 100.
3 VDC VOM COM 0 - 300 Divide by 100.
15 VDC VOM COM 0 - 15 Direct reading.
60 VDC VOM COM 0 - 60 Direct reading.
300 VDC VOM COM 0 - 300 Direct reading.
1.5 VAC VOM COM 0 - 15 Divide by 10.
3 VAC VOM COM 0 - 300 Divide by 100.
15 VAC VOM COM 0 - 15 Direct reading.
150 VAC VOM COM 0 - 15 Multiply by 10.
300 VAC VOM COM 0 - 300 Direct reading.
600 VAC VOM COM 0 - 60 Multiply by 10.
5.1.6 If code parameters are to be measured, select the desired
parameter using the Code Function Switch. Refer to Section 2.1 for
a description of these functions. Peak levels are measured using
the same scales as used in the NORM mode. Rate is read using the
black CODE RATE scale. On time is read using the black percentage
(%) scale. Code parameters may be read on any range provided
that the peak level is approximately ten percent of full scale.
5.1.7 Disconnect the test leads from the circuit under test and
return the Range Switch to the OFF position.
