Model 601SBM Low Profile Clamshell
92-0092 Rev. 131230
Parts List, Model 601SBM Clamshell Sub-Assembly
Item Part
No. No. Description Qty
1. 19-0280 HOUSING, MAIN 1
2. 24-0371 PLATE, BEARING BACKING 2
3. 24-0381 PLATE, BEARING BACKING 4
4. 24-0500 PLATE, THRUST 1
5. BAR ASSY, ADJUSTABLE 2
REFER TO SECTION ON CLAMPING PADS FOR OPTIONS
6. BAR ASSY, FIXED 2
REFER TO SECTION ON CLAMPING PADS FOR OPTIONS
7. 28-0057 SEAL, FELT 9”
(23 cm)
8. 28-0057 SEAL, FELT 17”"
(44 cm)
9. 29-0132 BEARING, MAIN 1
10. 32-0008 PIN, ROLL, 5/64 DIA x 1/4" 2
11. 32-0015 Pin, Roll, 3/32 DIA x 5/16" 2
12. 32-0153 PIN, DOWEL, 3/16 DIA x 1/2" 2
13. 33-0029 SCREW, CAP, #10-24 x 5/8" 6
14. 33-0040 SCREW, CAP, 1/4-20 x 3/4" 6
15 33-0043 SCREW, CAP, 1/4-20 x 1 1/4" 2
16. 33-1367 SCREW, SPLITLINE 2
17. 33-1369 SCREW, SET, 3/8-24 x 1/2", HDOG 8
18. 39-0269 HEADSTOCK 1
