8. TOOL BITS
Figure: 7. Typical Tool Bit Setup
99-4347
LH BEVEL, 37.5 O
99-0564
SEVER
99-4346
RH BEVEL, 37.5 O
99-4346
RH BEVEL, 37.5 O
30-0227
SPACER
30-0227
SPACER
99-4347
LH BEVEL, 37.5 O
1.125" (28.6 mm)
TOOL BIT SET-UP, 37.5 O - UP TO 1.125" (28.1 mm) WALL THICKNESS.
