Scotsman C0522R - Manual (Page 23)

January 2014
Page 22
C0522 through C1030
Remote Condenser Models - User Manual
13. Remove water distributors from ice machine.
Inspect distributor for restricted orifice holes. Be
sure all holes are full open.
14. Locate ice thickness sensor. Squeeze mounting
legs together to release sensor. Wash the metal
surfaces of the sensor and the adjustment screw
with ice machine scale remover solution. Also
wash the water distributor and curtain with the ice
machine scale remover solution.
15. Locate water level sensor. Squeeze catches
together and pull up to remove sensor. Wash
metal surfaces of sensor with ice machine scale
remover solution.
16. Mix a solution of sanitizer.
Note: A possible sanitizing solution may be made by
mixing 1 packed of Stera Sheen Green Label sanitizer
(available from Scotsman) with 2 gallons of warm (95-
115 o F.) potable water.
17. Thoroughly wash all surfaces of the ice thickness
sensor, water level sensor, curtain and water
distributor with the sanitizer solution.
18. Wash all interior surfaces of the freezing
compartment, including evaporator cover and right
side panel liner with the sanitizer solution.
19. Return water level sensor, ice thickness sensor,
water distributors and curtains to their normal
positions.
20. Push and hold the clean button to drain the
reservoir. Push and release the clean button again
and when the purge valve indicator light goes out,
immediately pour the remaining cleaning solution
into the reservoir.
21. Circulate the sanitizer solution for 10 minutes,
then push and release the Clean button.
22. Allow the water system to be flushed of sanitizer
for at least 20 minutes, then push and release the
Off button.
23. Return the evaporator cover and front panel to
their normal position and secure with the original
fasteners.
24. Push and release the On button to resume ice
making.
Ice Storage Bin
1. Remove and discard all ice.
2. Mix a solution of 7 ounces Scotsman Clear 1 ice
machine scale remover to 84 ounces of potable
water and wash all interior surfaces of the ice
storage bin to remove any mineral scale build up.
Pour excess cleaner solution into the bin’s drain.
3. Mix a solution of sanitizer and thoroughly wash
all interior surfaces of the ice storage bin. Pour
excess sanitizer solution into the bin’s drain
Squeeze Tabs Together, Slide Out Until it Stops
Then Lift to Remove
Inspect Orifice Holes
Release probes by pushing in on white buttons and
pulling probe down out of holder.
Remove and Inspect Water Distributor
