Parts list – Desa VSGF36NRA User Manual
Page 37
www.desatech.com
116746-01A
37
KEY PART
NO. NUMBER
DESCRIPTION
QTY.
1
113190-01CK Screen
2
2
116865-01CK Bottom Louver Assembly
1
3
**
Face Weldment
1
4
101355-03CK Hood
1
5
116864-01CK Louver Assembly
1
6
112862-02CK Firebox Bottom Bracket
1
7
21195
Right Firebox Support Leg
1
8
21194
Left Firebox Support Leg
2
9
**
Firebox Surround
1
10
**
Firebox Top Shield
1
11
**
Firebox Top
1
12
106687-01
Damper Can Collar
1
13
**
Insulation Pan
1
14
**
Fireplace Top Insulation
1
15
**
Fireplace Top
1
16
20280
Top Spacer
4
17
**
Fireplace Surround
1
18
107128-01
Gas Conduit
2
19
115408-01
Receptacle Plate
1
20
21171
Gas Knock-Out Cover
4
21
103771-01
Strain Relief
1
22
115402-01
Steel Receptacle Box
1
23
103581-02
Blower
1
24
M11084-38
Hex Screw, #8
3
25
GA3555
Duplex Outlet
1
26
115403-01
Steel Receptacle Cover
1
27
101378-01
Thermostat Switch
1
28
116460-01
Left Brick Refractory
1
29
116460-02
Rear Brick Refractory
1
30
116460-03
Right Brick Refractory
1
** Not a field replaceable part.
PARTS LIST
This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions
listed under Replacement Parts on page 26 of this manual.
