OPERATING FIREPLACE
Continued
Figure 32 - Setting the Selector Switch,
Control Knob and Flame Adjustment
Knob for Hand-Held Remote Operation
O
FF
P IL OT
LO
IH
REMOTE
OFF
ON
O
N
Selector Switch in Remote
Position (Optional Hand-
Held Remote Control)
Flame Adjustment Knob
Control Knob
in On Position
ON/OFF SERIES (MODEL HRC100)
Hold the control button on the hand-held remote
until burner turns on. Hold the control button
again until burner turns off (see Figure 33).
TO LOCK
press both buttons on hand-held
remote control until light stops flashing. Hand-
held remote control is now locked. If the fire is
on it will be turned off automatically. In the
locked state, the light will not light up when
any button is pressed.
TO UNLOCK
press both buttons together
on hand-held remote control until the light
stops flashing. The hand-held remote is now
unlocked.
Figure 33 - On/Off Hand-Held Remote
Control Unit (HRC100)
Control Button Turns
Burners On and Off
THERMOSTAT SERIES
(MODEL HRC200)
The hand-held remote can be operated using
either the manual mode (MANU) or thermo-
static mode (AUTO) (see Figure 34). To select
Fahrenheit/Centigrade mode display, carefully
press the ˚C/˚F mode button with the end of a
paper clip or similar blunt object.
Manual Mode
1. Press the POWER and LOCK buttons togeth-
er to turn on the hand-held remote control.
2. Press the MANU button to turn on the
fireplace.
3. Press the POWER and LOCK buttons
together to turn off the fireplace.
Figure 34 - Thermostat Hand-Held
Remote Control Unit (HRC200)
Auto (Thermostatic) Mode
1. Press the POWER and LOCK buttons
together to turn on the hand-held remote
control.
2. Press AUTO button to select this mode.
3. Set the desired room temperature by press-
ing the TEMP + or - buttons.
4. Press the POWER and LOCK buttons
together to turn off the fireplace
Note: Do not leave the hand-held remote in the
AUTO mode close to the fireplace. The radiant
heat from the fireplace will turn off the fireplace.
Ideally, place the hand-held remote in the center
of the room facing towards the fireplace.
Note:
Do not hold the hand-held remote for
a long time. Body temperature will affect its
operation in the AUTO mode.
Safety Features
When away from home for an extended period
of time or as a child safety feature to prevent
accidental ignition of the fireplace, the receiver
ON/OFF/REMOTE switch should be in the
OFF position.
Auto Shutoff Feature
1. If the average room temperature exceeds
82 degrees Fahrenheit (28 degrees Centi-
grade), the hand-held remote control will
perform a safety override and shut the
fireplace off. This feature is not available
in the MANU mode.
LOCK
MANU AUTO
ºC/ºF
TEMP
POWER
ROOM
TEMP SET
TEMP
AUTO
Turns
Hand-Held
Remote On
or Off and
Allows You
to Choose
the Manual
Setting
Selects
AUTO Mode
°C/°F Mode
Button
Locks
System to
Prevent
Accidental
Ignition
Turns
Burners
On or Off
Increases or Decreases
Room Temperature in
AUTO Mode
Digital Display Shows
Temperature and Settings
Indicator
Light
