www.desatech.com 116746-01A 33
PARTS LIST
This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions
listed under Replacement Parts on page 26 of this manual.
KEY PART NUMBER
NO. VSGF36PTA VSGF36NTA DESCRIPTION QTY.
1 109824-02 109824-02 Rear Burner Assembly 1
2 102239-02 102239-02 Front Burner Assembly 1
3
____
107634-01 NG Conversion Plate 1
4 101004-15 101004-11 Rear Burner Injector 1
5 101004-01 101004-08 Front Burner Injector 1
6 101008-01 101008-01 Crossover Burner Gasket 1
7 101007-01 101007-01 Crossover Ignition Burner 1
8 101006-02 101006-02 Pilot Bracket 1
9 104286-01 104285-01 ODS Pilot 1
10 098249-01 098249-01 ODS Nut 4
11 102846-01 102846-01 Burner Tube 1
12 ** ** Base Assembly 1
13 ** ** Firebox Bottom 1
14 115410-01 115410-01 Magnet and Bracket Kit 2
15 103650-01 103650-01 Knob 1
16 106683-01 106683-01 Firebox Support Leg 2
17 101382-01 101382-01 Valve Bracket 1
18 101329-22 101329-20 Thermostat Gas Valve 1
19 101381-01 101381-01 Cover and Piezo Valve 1
20 099387-09 099387-09 Pilot Tube 1
21 102845-01 102845-01 Inlet Tube 1
22 098867-10 098867-09 Gas Regulator 1
23 097809-03 097809-03 Male Fitting 1
24 101628-03 101628-03 Flex Hose 1
25 105649-01 105649-01 Blower Speed Control 1
26 103651-01 103651-01 Lock Nut 1
27 110881-04 110881-04 Front Log 1
28 110881-05 110881-05 Middle Log 1
29 110881-06 110881-06 Rear Log 1
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 Warning Plate 1
101054-01 101054-01 Lighting Instructions Plate 1
** Not a field replacement part
