Page 8 of 25 VP100/20NET
JP7 JP8 JP9 JP10 JP11 JP14 JP15 JP16 JP17 JP18 JP19
VP100/20 NET x x x x x active active 20 mA passive passive telegrams
VP100/20 20 mA active active passive passive x x x x x telegrams
Fig. 5: The use of 20 mA current loop; here the outputs are passive, and the inputs active.
2.4 Contacts of the relay
To the relay's connection terminals you can connect an external sound source, which will provide
sound accompaniment for the messages for which the "loud sound" option is checked. The figure
below shows the arrangement of the connection terminals.
1
4
VP100/20NET
Conn. RELAY
2
3
5
6
Fig. 6: The relay's connection terminals.
100
24
17
100
25
23 100
24
17
100 25
23
+V2
+V1
VP100/20 NET
Connector
OUT
VP100/20 NET
Connector
IN
