T14D: Blast Chiller/Shock F
reez
er
67.95”(172.6)
43.31”(110.0)
29.92”(75.9)
73.23”(186.0)
73.95”(187.8)
43.31
31.50”(80.0)
28.78
25.98”(65.9)
6.00”(15.2)
39.29 41.10
27.56”(70.0)
28.78”(73.1)
67.95”(172.6)
43.31”(110.0)
29.92”(75.9)
73.23”(186.0)
73.95”(187.8)
43.31
31.50”(80.0)
28.78
25.98”(65.9)
6.00”(15.2)
39.29 41.10
27.56”(70.0)
28.78”(73.1)
Model Voltage Comp. H.P. Total Max Amps Max Fuse Size
Average Heat Rejected
(W)
Ship Weight
T14D 220-230/3/60 3.0 20.0 20.0 9,900 650
NEMA 15-30P
X
Y
Z
G
G
NEMA 6-15P
30 AMP 3-PHASE
15 AMP 1-PHASE
by Delfield ®
38 38 0
™
Sample Printout
