Project __________________________________
Item ____________________________________
Quantity ________________________________
CSI Section 11400
Approved _______________________________
Date ____________________________________
980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858
Phone: 800-733-8948 or 989-773-7981
Fax: 800-669-0619
www.delfield.com
Exterior top is one-piece, 22-gauge stainless steel with
integral 2.12” (5.4cm) square nosing on the front.
Exterior back and bottom are two-piece 24-gauge galvanized
steel. Exterior ends are stainless steel.
Interior sides are thermoformed ABS plastic with integral
shelf supports. Interior back is one-piece 22-gauge stainless
steel. Interior bottom and top are thermoformed ABS plastic.
Base is fully insulated with high-density foamed in place
environmentally friendly, Kyoto Protocol Compliant, Non
ODP (Ozone Depletion Potential), Non GWP (Global Warming
Potential) polyurethane.
Refrigeration system uses HFC-404A refrigerant. Compressor
is 1/3 H.P., with condenser coil and condensate evaporator
mounted on rear of the cabinet. Evaporator coils are located
on the interior rear wall of the cabinet. Refrigerant flow is
controlled by a thermal expansion valve. Cabinet maintains
an interior cabinet temperature of -5°F to 0°F (-21°C to -18°C).
Electronic control is located on the exterior back of the
cabinet. It allows the unit to maintain consistent temperatures
in heavy duty conditions.
Electrical connections are 115 volt, 60 Hertz, single phase.
Unit has a 6’ (1.8m) long electrical cord and NEMA 5-15P plug.
Casters: Equipment is mounted on 3” (7.6cm) diameter plate
casters. Equipment clearance above the floor is 0.82” (2cm).
Doors have a 24-gauge stainless steel exterior, with
thermoformed ABS plastic interior liner. Cabinet of door
models has one adjustable epoxy-coated wire shelf.
Specifications
Standard Features
Options &
Accessories
• All 4400 and 4500 Series units are 100% front
breathing, which allows the unit to be pushed
against a wall or built into a cabinet or an
existing line up
• Durable, rugged stainless steel sides, top and
front
• Features Delfield’s exclusive ABS interior. ABS
is extremely durable - it won’t dent, chip or
corrode and is backed by a limited lifetime
warranty
• Heavy duty self-closing hinges
• Environmentally friendly R404A refrigerant
• High density foamed in place environmentally
friendly, Kyoto Protocol Compliant, Non ODP
(Ozone Depletion Potential), Non GWP (Global
Warming Potential) polyurethane keeps energy
costs low
• Black recessed quick grip handle
• Standard on 3” casters for easy cleaning and
installation
• 115V, 60-cycle single phase electrical system
• 6’ cord and plug supplied
• One epoxy coated wire shelf standard, installed
per door section
• UC4560N Two section freezer, undercounter with doors
Models
UC4560N Undercounter
Reduced Height Front-Breathing Self-Contained
Undercounter Freezer Bases
UC4560N Under
count
er
: R
educed Height F
ront
-Br
eathing S
elf-
Contained Under
count
er F
reez
er Bases
• Electronic control
• Three year parts and labor warranty
and an additional two year compressor
parts warranty
• 18” wide single tier overshelf
• Stainless steel finish on back
• Plastic laminate on front
• Additional wire shelves
• Door lock (solid door models only)
• Exterior thermometer (solid door
models only)
• Interior lights*
• 220V/50 Hertz electrical system*
* Inclusion of this option will alter electrical
specifications of the unit
UC4560N
