Delfield ST4560N User Manual

St4560n flat top, Models

background image

Project __________________________________

Item ____________________________________

Quantity ________________________________

CSI Section 11400

Approved _______________________________

Date ____________________________________

980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858

Phone: 800-733-8948 or 989-773-7981
Fax: 800-669-0619

www.delfield.com

Exterior top is one-piece, 22-gauge stainless steel with integral
2.12” (5.4cm) square nosing on the front. The backsplash is full
width and 4” (10cm) tall.

Exterior back and bottom are two-piece 24-gauge galvanized
steel. Exterior ends are stainless steel.

Interior sides of door models are thermoformed ABS
plastic with integral shelves supports. Interior back is one-
piece 22-gauge stainless steel. Interior bottom and top
are thermoformed ABS plastic. Base is fully insulated with
high-density foamed in place environmentally friendly, Kyoto
Protocol Compliant, Non ODP (Ozone Depletion Potential),
Non GWP (Global Warming Potential) polyurethane.

Refrigeration system uses HFC-404A refrigerant. Compressor
is 1/3 H.P., with condenser coil and condensate evaporator
mounted on rear of the cabinet. Evaporator coils are located
on the interior rear wall of the cabinet. Refrigerant flow is
controlled by a txv valve. Cabinet maintains an interior cabinet
temperature of -5°F to 0°F (-21°C to -18°C).

Electronic control is located on the exterior back of the
cabinet. It allows the unit to maintain consistent temperatures
in heavy duty conditions.

Electrical connections are 115 volt, 60 Hertz, single phase.
Unit has a 6’ (1.8m) long electrical cord and NEMA 5-15P plug.

Casters: Equipment is mounted on 5” (13cm) diameter plate
casters with front two locking. Equipment clearance above the
floor is 2.5” (6cm).

Doors have a 24-gauge stainless steel exterior, with
thermoformed ABS plastic interior liner. Cabinet of door
models has one adjustable epoxy-coated wire shelf.

Specifications

Standard Features

Options &
Accessories

• All 4400 and 4500 Series units are 100% front

breathing, which allows the unit to be pushed
against a wall or built into a cabinet or an
existing line up

• Durable, rugged stainless steel sides, top and

front

• Features Delfield’s exclusive ABS interior (on

sides). ABS is extremely durable - it won’t dent,
chip or corrode and is backed by a limited
lifetime warranty

• Heavy duty self-closing hinges
• “ST” prefix models have a 4” stainless steel

backsplash

• Environmentally friendly R404A refrigerant
• High density foamed in place environmentally

friendly, Kyoto Protocol Compliant, Non ODP
(Ozone Depletion Potential), Non GWP (Global
Warming Potential) polyurethane keeps energy
costs low

• Black recessed quick grip handle
• Standard on 5” casters for easy cleaning and

installation

• 60-cycle single phase electrical system
• 6’ cord and plug supplied

ST4560N

Single section freezer, flat top with doors

Models

ST4560N Flat Top

Front-Breathing Self-Contained Flat Top Freezer Bases

ST4560N F

lat

Top: F
ront
-Br

eathing S

elf-
Contained F

lat

Top F
reez
er Bases

• One epoxy coated wire shelf standard,

installed per door section

• Electronic control
• Three year parts and labor warranty

and an additional two year compressor
parts warranty

• 18” wide single tier overshelf
• Stainless steel finish on back
• Plastic laminate on front
• Additional wire shelves
• 3” casters, 3.75” ride height
• Door lock (solid door models only)
• Exterior thermometer (solid door

models only)

• Interior lights
• 220V/50 Hertz electrical system*

* Inclusion of this option will alter

electrical specifications of the unit

ST4560N
