Top is stainless steel. Top mounts a 9.50” (24cm) high glass
filler over die-stamped drain opening fitted with chrome-
plated wire strainer. Bin opening is die-stamped with 0.19”
(0.5cm) raised edge, measures 10.50” x 15.13” (27cm x 38cm),
has one-piece lift-off stainless steel cover.
Bin liner is high-impact ABS plastic, has covered corners and is
pitched to 1.00” (3cm) diameter drain. Sides and bottom of bin
insulated with high-density environmentally friendly, Kyoto
Protocol Compliant, Non ODP (Ozone Depletion Potential),
Non GWP (Global Warming Potential) polyurethane. Bin holds
45 pounds of ice.
Exterior housing is 24-gauge galvanized steel.
Specifications
Standard Features
Options &
Accessories
• Stainless steel top with raised die stamped
opening
• One-piece stainless lift off cover with handle
• ABS plastic interior liner with covered
corners
• 1” diameter drain plumbed out the bottom
• High-density environmentally friendly,
Kyoto Protocol Compliant, Non ODP (Ozone
Depletion Potential), Non GWP (Global
Warming Potential) polyurethane foam
throughout unit
• Exterior tank is made of galvanized steel
• Glass filler is 9.50” high, over a dies stamped
drain opening fitted with chrome plated
wire strainer
• One year parts and 90 day labor standard
warranty
•
248
31.00” x 15.00” x 22.60” water and ice station
Models
248 Series
Water And Ice Station
248 S
er
ies:
W
at
er And Ice Station
• Pitcher filler
