Table: Diagnostic Table
Table Title
Description
OP#
Displays the OP number
Status
Displays the Status of the System. Note it should display “OK”. If you see
an error, contact Lencore at 516-682-9292
RAM/FLASH
Displays the Status of the Ram and FLASH. Note it should display
“OK/OK”. If you see an error, contact Lencore at 516-682-9292
DSP
Displays the DSP code version
Neuron
Displays the Neuron code version
MA A
Displays the Masking volume for channel A in dB
MA B
Displays the Masking volume for channel B in dB
MA C
Displays the Masking volume for channel C in dB
MA D
Displays the Masking volume for channel D in dB
MC A
Displays the Masking contour for channel A
MC B
Displays the Masking contour for channel B
MC C
Displays the Masking contour for channel C
MC D
Displays the Masking contour for channel D
PA A
Displays the Paging volume for channel A in dB
PA B
Displays the Paging volume for channel B in dB
PA C
Displays the Paging volume for channel C in dB
PA D
Displays the Paging volume for channel D in dB
MuA A
Displays the Music volume for channel A in dB
MuA B
Displays the Music volume for channel B in dB
MuA C
Displays the Music volume for channel C in dB
MuA D
Displays the Music volume for channel D in dB
