57

Chapter 2. Getting Started the BHT-7000 and System Mode

[4.5-3]

Setting the interface port

Selecting the "3:COM PORT" on the SET COMMU-
NICATION menu calls up the screen shown at left.

Highlighted is the current setting.

1 BASIC:

Selects the optical or direct-

connect interface port to be
used

for user programs

w r i t t e n i n B H T - B A S I C
(OPEN "COM:" or XFILE
statement).

2 SYSTEM MODE:

Selects the optical or direct-

connect interface port to be
used

for downloading or

uploading files in System
Mode.

Select a desired item by using the numerical keys
or

* and

* keys, and then select a desired

setting by using the

* and

* keys.

To return to the SET COMMUNICATION menu,
press the C key.

* For BHT-7000s having a 26-key pad, use F5 , F6 , F7 and F8 keys instead of

,

,

, and

keys, respectively

SET COM DEFAULT PORT

1:BASIC

Optical

Connector

2:SYSTEM MODE

Optical

Connector
