In addition to the functions given on the previous page, System Mode has these four
functions: Deleting files, Downloading/uploading the BHT system parameter file, Set-
ting the remote wake-up parameters, and Downloading/uploading the system mes-
sage file.

To call up these functions, press the 0 , 3 , 4 or 6 key, respectively, while holding
down the SF key when the SYSTEM MENU is displayed.

SYSTEM MENU

⇐

Press the PW key while holding down the
SF and 1 keys.

Deleting Files

Deletes a program file or data file
stored in the memory.

(Refer to Subsection 2.6.3, [ 7 ].)

0 with
SF held
down

3 with
SF held
down

4 with
SF held
down

SYSTEM MENU

1:EXECUTE PROGRAM

2:DOWNLOAD
3:UPLOAD
4:SET SYSTEM
5:TEST
6:VERSION

DELETE FILE

SAMPLE01.PD3

SAMPLE02.PD3
SAMPLE03.PD3
SAMPLE04.PD3
SAMPLE05.PD3
SAMPLE06.PD3

SYSTEM PARAMETER

1:DOWNLOAD

2:UPLOAD

SET REMOTE WAKEUP

1:REMOTE WAKEUP

OFF

2:TRANSMIT SPEED

9600

19200 38400

57600 115200

SYSTEM MESSAGE

1:DOWNLOAD

2:UPLOAD

Downloading/uploading the BHT
system parameter file

Downloads or uploads the system
parameter file.

(Refer to Subsection 2.6.3, [ 8 ].)

Setting the remote wake-up param-
eters

Sets the remote wake-up parameters.

(Refer to Subsection 2.6.3, [ 9 ].)

Downloading/uploading the system
message file

Downloads or uploads the system
message file.

(Refer to Subsection 2.6.3, [ 10 ].)

6 with
SF held
down
