Parts List
Ersatzteileliste
Liste de pièces
パーツリスト
7
En
Parts # Qty Description
Parts List
1503
2057
3062
4884
4894
6122
6154
6816
6819
6878
7801
15135
15181
50474
72140
85250
85252
85256
85260
85262
85265
85617
85618
85619
85620
85621
85622
85623
85624
85625
85627
86021
86094
86810
86812
86813
86816
86869
86880
86895
86900
87612
87613
87614
87615
87616
87617
87623
87630
87635
88065 1
1
2
2
2
10
10
6
5
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
6
1
1
2
1
1
2
10
2
1
1
1
1
1
1
1
1
1
1
GLOW PLUG MEDIUM COLD R4
EXTENSION WIRE FOR RECEIVER BATERY 220mm
CLASSIC KING WHEEL CHROME (2.2in)
MOUNTED DUAL-STAGE TIRES ON CLASSIC KING WHEELS
MUD THRASHER TIRES (135x73mm)
BODY PIN (MEDIUM)
NYLON STRAP (3.5x150mm/BLACK)
SILICONE O-RING S10
SILICONE O-RING P-3 (RED)
SHOCK SHAFT 3x61mm
NWK-1 TRUCK PAINTED BODY (RED/BLACK)
STARTING SHAFT 6x20x20mm (NITRO STAR T-15L)
NITRO STAR T-15L ENGINE WITHOUT PULLSTART
SILICONE TUBE 2x5x300mm
AIR CLEANER 30mm
AXLE/DIFFERENTIAL CASE SET (FRONT/REAR)
HUB CARRIER SET (RIGHT/LEFT)
SHOCK PARTS/SHOCK TOWER SET
SERVO SAVER / PIVOT BALL SET
ROD BRACE SET
SKID PLATE/FRONT BUMPER SET
CENTER GEAR BOX SET
RADIO BOX SET
UPPER ARM SET
ARM ROD SET
UNIVERSAL CENTER DRIVE SET 66mm (ASSEMBLED)
THROTTLE ARM/HEX WHEEL HUB SET
WHEELY BAR SET
GEAR SET
SPUR GEAR 53T
FUEL TANK (100cc)
FLYWHEEL (with COLLET and PINS)
SCREW SHAFT M4x2.5x12mm (BLACK)
GEAR SHAFT 5x6x29mm
DRIVE SHAFT 6x32mm
DRIVE SHAFT 6x82mm
THREAD SHAFT M3x102mm
CLUTCH SHOE/SPRING SET
SLIPPER PRESSURE PLATE
CAP HEAD SCREW M3x30mm
SLIPPER PAD
HPI NITRO START CASE SET
HPI NITRO START GEAR BOX SET
HPI NITRO START CASE PARTS SET
HPI NITRO START GEAR SET
HPI NITRO START MOTOR/SWITCH SET
HPI NITRO START STARTER SHAFT (280mm)
HPI NITRO START BACK PLATE SET (T SERIES ENGINES)
HPI NITRO START SYSTEM (STARTER UNIT)
HPI NITRO START SYSTEM (T SERIES ENGINE)
MAIN CHASSIS SET
Parts # Qty Description
88068
88069
88070
88078
88120
88121
88122
88125
88145
102599
102600
A249
A431
A805
A811
A850
A855
A875
B022
B030
B046
Z150
Z214
Z224
Z242
Z244
Z264
Z281
Z282
Z290
Z421
Z488
Z509
Z517
Z519
Z527
Z543
Z561
Z567
Z569
Z571
Z578
Z663
Z684
Z694
Z705
Z852
Z892
Z903
Z904
Z950 1
1
1
1
1
2
1
1
1
2
4
4
1
1
1
1
1
5
2
2
1
1
4
10
20
10
10
4
4
4
12
6
6
10
6
6
6
6
10
10
6
10
6
4
10
6
10
10
1
1
1
TUNED PIPE SET
EXHAUST HEADER SET
ENGINE MOUNT SET
DRIVE SHAFT SET
BRAKE CAM SHAFT/BRAKE PLATE SET
AXLE 5x50mm
THROTTLE ROD/BRAKE ROD SET
SLIPPER PLATE SET
SILICONE EXHAUST COUPLING SET
BALL BEARING 6x11x4mm
SHOCK SPRING SET (FRONT/REAR/BLACK)
BALL M2x3.8x4.5mm
DIFF CASE
PILOT SHAFT M5
CLUTCH BELL 11 TOOTH (1M)
DIFF BEVEL GEAR SET (13T/10T)
DIFF FINAL GEAR SET (P1x38T/P1x13T)
EX GASKET
BALL BEARING 5x11x4mm
BALL BEARING 10x15x4mm
CLUTCH NEEDLE BEARING 5x8mm
ANTENNA PIPE SET
BUTTON HEAD SCREW M3x8mm
WASHER M3x8mm
E CLIP E2mm
E CLIP E-4
PIN 2x10mm SILVER
STEP SCREW M3x12mm
STEP SCREW M3x14mm
STEP SCREW M4x15mm
CAP HEAD SCREW M2.6x8mm
TP. FLANGED SCREW M2.6x12mm
BUTTON HEAD SCREW M3x30mm
BINDER HEAD SCREW M3x8mm
BINDER HEAD SCREW M3x15mm
FLAT HEAD SCREW M3x10mm
CAP HEAD SCREW M3x10mm
TP. FLANGED SCREW M3x10mm
TP. BINDER HEAD SCREW M3x10mm
TP. BINDER HEAD SCREW M3x15mm
TP. BINDER HEAD SCREW M3x20mm
TP. FLAT HEAD SCREW M3x12mm
LOCK NUT M3
FLANGED LOCK NUT M4
WASHER M5x10x0.5mm SILVER
SET SCREW M3x10mm
WASHER 5x7x0.2mm
WASHER 10x12x0.2mm
ALLEN WRENCH 2.5mm
ALLEN WRENCH 2.0mm
CROSS WRENCH (SMALL)
