Page 4
System Components
NOTE
Actual component pieces may vary from these
images. Refer to your project submittal drawing.
Vektor-MD Assembly View - Direct Drive
Belt and direct drive units share similar system
components and assembly configuration.
Blower Housing
Windband
Nozzle
Bypass Air Plenum
Roof Curb or
Structural Support
Vektor-MH Assembly View - Belt Drive
Belt and direct drive units share similar system
components and assembly configuration.
Blower Housing
Nozzle
Bypass Air Plenum
Roof Curb or
Structural Support
Drain
Motor
Flex Coupling
Shaft Bearing
Fan
Shaft
Direct Drive
Bypass Damper
Actuator Access Door
Weatherhood
with Birdscreen
Isolation Damper
Blower Housing
Access Door
Access Panel
Bolted / Gasketed
(all sides)
Isolation Damper
Actuator Cover
Motor Cover/Access
Weatherhood
with Birdscreen
Panel Lifting
Lugs
Isolation Damper
Isolation Damper
Actuator Cover
Blower Housing
Access Door
Access Panel
Bolted / Gasketed
(all sides)
Bypass Damper
Actuator Access Door
Motor Cover
Lifting Lug
Panel
Lifting
Lugs
4
