Dynacord DMM 4650 - Manual (Page 43)

Sequence Nummer
S 34
Title
“gen-emgc”
Priority
95
Stopp trigger
off
Step Command Parameter
1: Out A1 set
2: wt In A1 High
3: Out B4 clr
4: Out B2 set
5: Out B3 set
6: Out A3 set
7: Sum= off
8: DMM= -5dB
9: Start A 30
10: wt Audio
11: Start A 31
12: wt Audio
13: Jump 09
14: End
Sequence Nummer
S 35
Title
“fireship”
Priority
95
Stopp trigger
off
Step Command Parameter
1: Out A1 set
2: wt In A1 High
3: Out B4 clr
4: Out B2 set
5: Out B3 set
6: Out A3 set
7: Sum= off
8: DMM= -5dB
9: Start A 32
10: wt Audio
11: Start A 31
12: wt Audio
13: Jump 09
14: End
Ship alarm “General Emergency”
Description: Turns the sound reinforcemnet system’s power on
(relay A1) and waits for acknowledgment (input A1 = system
ready). When the system is ready, the output B4 (music program
off) is opened and B2, B3 (mandatory reception E, D) gets closed.
Closing the signaling contact (A3 = alarm signal running) swit-
ches the audio controls to the alarm signal’s priority. The signal
sequence is defined as follows: 7 packages 1.5 sec. 800 Hz tone
with 1.5 sec. break (A30) followed by a 4.5 sec. tone with 1.5 sec.
break (A31). The sequence runs continuously until it is stopped
by a sequence with a higher priority (e. g. S 20). The control of
settings and relay contacts is taken over by the stop sequence.
After the stop sequence ends, the DMM 4650 returns to stand-by
mode.
Ship alarm “Fire”
Description: Turns the sound reinforcement system’s power on
(relay A1) and waits for acknowledgment (input A1 = system
ready). When the system is ready, the output B4 (music program
off) is opened and B2, B3 (mandatory reception E, D) is closed.
Closing the signaling contact (A3 = alarm signal running) swit-
ches the audio controls to the alarm signal’s priority. The signal
sequence is defined as follows: 1 package 1.5 sec. 800 Hz tone
with 1.5 sec. break (A32) followed by a 4.5 sec. tone with 1.5 sec.
break (A31). The sequence runs continuously until it is stopped
by a sequence with a higher priority (e. g. S 20). The control of
settings and relay contacts is taken over by the stop sequence.
When the stop sequence ends, the DMM 4650 returns to stand-
by mode.
43
