Command parameter Function
Nop -no operation
End -ending the running sequence
Out X.Y set -Output Y (1 ..4) of the I/O module X (A..D) is set to 1 (contact closed)
X.Y clr -Output Y (1 ..4) of the I/0 module X (A..D) is set to 0 (contact open)
X.Y inv -Output Y (1 ..4) of the I/O module X (A..D) is inverted
Start Axx -ends a currently running audio signal immediately and starts the alarm preset xx
Gxx -ends a currently running audio signal immediately and starts the gong preset xx
Mxx - ends a currently running audio signal immediately and starts the message xx
Ann. -ends a currently running audio signal immediately and starts the announcement
Break - ends a currently running audio signal immediately
Finish - requests the end of the running audio signal. Gong, alarm fade out, messages and
announcements are finished, recording is stopped.
DMM= -xx dB - controls of the DMM 4650 audio signal is set to -xx dB (*0 dB default)
Sum= -xx dB - control of the input - output XLR connection is set to -xx dB
Bypass set - analog bypass relay, direct connection XLR input - output closed
clr -analog bypass relay, no relay connection XLR input - output
inv -inverted analog bypass relay
Audio prl -switches the started DMM audio signals to pre-listen outputs (Pre-Listen only)
sum -switches the started DMM audio signals to pre-listen and sum outputs (*default)
Record Mxx -ends a currently running audio signal immediately and starts the recording of the
message xx. At first this message is being erased and then recording starts at the last
adjusted recording level. Audio quality and name of this message stay unchanged.
The message priority is identical with the sequence priority. The execution time lasts
until End Delete Message (start of recording).
Dly= ttt,t s -sets a timer to ttt,t seconds and starts measuring this time (sand glass).
Count= xxxx - sets a counter (event counter) to a starting value xxxx. With every “if count”-command
the counter is decremented by 1 until 0 is reached.
Jump xx - resumes the sequence at step number xx.
if Delay - only executes the next step number if the delay time has elapsed (see command Dly).
Otherwise the next step number is being skipped.
Count -the counter is decremented by 1. The next step number is executed only if the counter
has reached 0 (see command Count). If the counter value is greater than 0, the next
step number is being skipped.
Audio -executes the next step number only if the audio signal started at last is finished
(see command start), otherwise the next step number is being skipped.
In X,Y Z -executes the next step number only if the desired level Z (H or L) is applied at input
Y (1 ..4) of the I/O module X (A..D). If this condition is not fulfilled, the next step number
is being skipped.
Stop -executes the next step number only if the stop trigger condition of this sequence is
fulfilled. Otherwise the next step number is being skipped.
wt Delay - waits until the delay time is elapsed
Audio -waits until the last started audio signal is finished
In X,Y Z -waits until the desired level Z (H or L) is applied at input Y (1 ..4) of the I/O
module X (A..D).
Stop -waits until the stop trigger condition of this sequence is fulfilled.
List of available step functions in sequences
* setting which is utilized, if a command is not used
