Sequence Nummer
S 28
Title
“Message2”
Priority
80
Stopp trigger
off
Step
Command Parameter
1:
Out
C1 set
2:
Sum=
off
3:
DMM=
-2dB
4:
Start
M 02
5:
wt
Audio
6:
End
Sequence Nummer
S 29
Title
“EasyRec1”
Priority
80
Stopp trigger
C3 High >00,1s lat
Step
Command
Parameter
1:
Out
C3 set
2:
Record
M 01
3:
Out
C2 set
4:
Dly=
010,0 s
5:
if
Stop
6:
Nop
7:
if
Stop
8:
Jump
14
9:
if
Delay
10:
Jump
14
11:
if
Audio
12:
End
13:
Jump
07
14:
Finish
15:
Out
C2 clr
16:
Jump
11
Start Message 2
Description: Closing the signaling contact (C1 = message runs)
switches the audio controls to the priority of the message. After
the message is finished the DMM 4650 returns to the stand-by
mode.
Starts the recording of Message 01 (remote recording),
starts by briefly pressing the input C3 button (menu trigger),
stops by pressing the input C3 button again
Description: Closing the signaling contact (C3 = remote recording
runs) starts erasing the message. After successful erasing the
signaling contact C2 (=start recording) is being closed. The
recording is terminated by switching the control input C3 (current
input C3 on). If the termination of the recording mode is not
recognized, the maximum duration is limited to 10 sec. Name and
priority of the message stay unaltered and the DMM 4650 returns
to the stand-by mode.
