Sequence Nummer
S 25
Title
“Vierklng”
Priority
89
Stopp trigger
off
Step Commend Parameter
1: Out A1 set
2: wt In A1 High
3: Out B4 clr
4: Out B2 set
5: Out B3 set
6: Out A4 set
7: Sum= off
8: DMM= -5dB
9: Start G 20
10: wt Audio
11: End
Sequence Nummer
S 26
Title
“Vorgong”
Priority
87
Stopp trigger
B4 Low >00,1s stc
Step Command Parameter
1: Out B4 clr
2: Out B2 set
3: Out B1 set
4: Sum= -3dB
5: DMM= -5dB
6: Start G 24
7: Dly= 004,0 s
8: wt Delay
9: Out B1 clr
10: wt Audio
11: wt Stop
12: End
Sequence Nummer
S 27
Title
“Message1”
Priority
80
Stopp trigger
off
Stepp Command Parameter
1: Out C1 set
2: Sum= off
3: DMM= -2dB
4: Start M 01
5: wt Audio
6: End
4-tone gong
Description: Turns the sound reinforcement system on (relay A1)
and waits for acknowledgment (input A1 = system ready). When
the system is ready, the output B4 (music program off) is being
opened and B2, B3 (mandatory reception E, D) gets closed. After
closing the signaling contact (A4 = gong runs) the audio controls
are set to gong priority. The gong signal is being output and
fades. After the fade-out the DMM 4650 returns to stand-by
mode.
Start Pre-gong (key B4 on), end of announcement with key
B4 off
Description: The output B4 (music program off) is opened and in
succession B2 (mandatory reception E) is being closed. After
closing the signaling contact (B1 = pre-gong runs) the audio
controls are set to audio input/pre-gong mix. After 4 seconds the
signaling contact (B1, ready for announcement) is being opened.
The audio controls remain unchanged until control input B4
terminates the sequence. Afterwards, the DMM 4650 re-enters
the stand-by mode.
Start Message 1
Description: After closing the signaling contact (C1 = message
runs) the audio controls are set to prioritize this message. After
the message is finished the DMM 4650 re-enters the stand-by
mode.
