Programming and Set Up
N OTE : The Model 13382 WiFi and 13383 VoIP Addressable Amplified Speakers include the same
embedded browser as do GAI-Tronics’ VoIP and WiFi telephones. There are many programmable
parameters utilized by our telephones that are not utilized by the VoIP Amplified Speakers. All speakers
are factory programmed for maximum operating proficiency. Please do not make any programming
changes other than those directed in this manual.
Opening the Addressable Amplified Speaker
The Addressable Amplified Speaker must be opened for programming and installation. Bench
programming and testing is recommended. Remove the speaker from the carton and position on a flat
surface with the front of the speaker facing up. Although the front section attaches to the rear section
with six Phillips screws, only two screws have been secured during the production process. Back out the
two screws on the left and right side of the speaker. All screws are captive and will remain in the front
section. Lift the front section straight up and flip to the left-hand side of the rear section. Refer to Figure
2.
Figure 2: Addressable Amplified Speaker (Model 13382 shown)
