Pub. 42004-462A
Model 13382 WiFi and 13383 VoIP Addressable Amplified Speakers Page 8 of 24
f:\standard ioms - current release\42004 instr. manuals\42004-462a.doc
12/13
Replacement Parts and Kits
Table 2. Replacement Parts and Kits
Part No. Description 13382 13383
61512-038 Wiring Harness, VoIP Weatherproof Amplified Speaker  
13327-021 Speaker  
19101-037 WLAN Antenna, SMA Wireless 
61531-055 Cable, WiFi Power 
69625-001 PCBA, VoIP Broadcast Carrier  
69868-001 PCBA, Ethernet Wireless Interface 
12506-001 Remote Volume Control L-Pad (optional)  
40419-015 Power Supply, 120/240 V ac, 15 V dc output  
61007-043 Patch Cable, Cat5e 350 MHz  
100-02-7013-000 VoIP Interface PCBA  
Performance Specifications
Power Options
AC Power Requirements (utilizing plug-in power supply provided with unit)
Input voltage ............................................................................................................. 120/240 V ac, 50/60 Hz
Input current ...................................................................................... 0.35 A @ 120 V ac, 0.2 A @ 240 V ac
Power over Ethernet (PoE) Requirements (Model 13382 only)
Power .............................................................................................................. 802.3af compliant (via RJ45)
Audio
Output
Speaker output power
With PoE or 15 V dc power supply ......................................................................... 8 W into 8-ohm load
With 24 V dc power source ................................................................................... 30 W into 8-ohm load
Sound pressure level
@ 8 W ................................................................................................................. 115 dB SPL, at 1 meter
@ 30 W................................................................................................................ 118 dB SPL, at 1 meter
Line out (into 600 ohms) ................................................................................................................. 1.0 Vrms
Frequency response .................................................................................................................... 300–3000 Hz
Dispersion
Nominal coverage when surface-mounted to wall (ref. −6 dB)
Vertical ........................................................................................................................................ Upward: 40
º
Downward: 60º
Horizontal .................................................................................................................................................. 90º
