1

UNPACKING & SET-UP

Check package for shipping damage. If there is shipping damage, do not discard the box.

SPECIFICATIONS

Speed:

5-level speed adjustment: 42, 64, 89, 114, 140 sheets/minute

Feed Tray Capacity:

Up to 400 sheets

Paper Size:

5” - 17” H x 4” - 11” W
Paper must not have staples, clips, adhesive or holes.

Paper Weight:

13# bond - 110# index (58 - 175 gsm)

Min./Max. Burst Length:

2.5” - 9.9”

Dimensions:

32” L x 9” H x 16” D

Weight:

56 lbs.

Voltage:

120V, 60 Hz

Preparation Before Using Machine

1. Remove the setscrew from the right side of the

paper stacker, and insert the axis into the holes

of the machine frame on the both sides.

Then install the paper stacker with the setscrew

removed.

2. Remove the thumb screws in the circles and

attach the columns on the right and left hooks,

and fasten thumb screws.

4. Remove the screw in the circle in the right picture

and install the paper holding plate (attachment).

Set the paper stopper and the paper guides as

shown in the picture.

5. Insert the edge of the support tray into the right

and left columns of the paper feed part of the main

body. Then, set the support tray downwards.

17

4. Insert the edge of the support tray into the right and left

columns of the paper infeed tray. Then set the support

tray downward.

1. Facing the output side, remove the setscrew from the

right side of the paper stacker, and insert the axis into

the holes of the machine frame on both sides. Then

install the paper stacker with the setscrew removed.

2. Remove the thumb screws (in the circles) and attach

the columns on the right and left hooks, then fasten the

thumb screws.

3. Remove the screw (see circled area, right) and install

the paper holding plate attachment. Set the paper stop-

per and paper guides as shown in the picture.

Preparation Before Using Machine

1. Remove the setscrew from the right side of the

paper stacker, and insert the axis into the holes

of the machine frame on the both sides.

Then install the paper stacker with the setscrew

removed.

2. Remove the thumb screws in the circles and

attach the columns on the right and left hooks,

and fasten thumb screws.

4. Remove the screw in the circle in the right picture

and install the paper holding plate (attachment).

Set the paper stopper and the paper guides as

shown in the picture.

5. Insert the edge of the support tray into the right

and left columns of the paper feed part of the main

body. Then, set the support tray downwards.

17
