PS420
Users Manual
24
Arrhythmias: Conduction Defects
Code Display Selects:
47 RT BNDL BB Right bundle branch block
rhythm.
48 LT BNDL BB Left bundle branch block
rhythm.
49 1ST DEG BL 1st degree heart block rhythm.
50 2ND DEG BL 2nd degree heart block rhythm.
51 3RD DEG BL 3rd degree heart block rhythm.
ST Elevation and Depression Waves
These can be set through direct code entry, as below, or
adjusted and set through first selecting 52 = ST WAVES
or 142 = ST WAVES. After selecting 52 or 142, press
ENTER, and then use the CHANGE keys
to scroll to
the available presets.
Code Display Selects ST wave of:
236 ST +.8 mV +.8 mV elevation
237 ST +.7 mV +.7 mV elevation
238 ST +.6 mV +.6 mV elevation
239 ST +.5 mV +.5 mV elevation
240 ST +.4 mV +.4 mV elevation
241 ST +.3 mV +.3 mV elevation
242 ST +.2 mV +.2 mV elevation
243 ST +.1 mV +.1 mV elevation
244 ST - .1 mV -.1 mV depression
245 ST - .2 mV -.2 mV depression
246 ST - .3 mV -.3 mV depression
247 ST - .4 mV -.4 mV depression
248 ST - .5 mV -.5 mV depression
249 ST - .6 mV -.6 mV depression
250 ST - .7 mV -.7 mV depression
251 ST - .8 mV -.8 mV depression
