8 DR ® VERTICAL/HORIZONTAL LOG SPLITTER
Specifications
Model 22 Ton 28 Ton 34 Ton
Engine See engine manual See engine manual See engine manual
Pump Two-Stage, 10 gpm Two-Stage, 10 gpm Two-Stage, 15 gpm
Cylinder (Bore x Stroke) 4 in. x 24 in. 4.5 in. x 24 in. 5 in. x 24 in.
Maximum Splitting Force 22 Tons* 28 Tons* 34 Tons*
Hydraulic Pressure 3400 psi* 3450 psi* 3500 psi*
Maximum Log Length 25 in. 25 in. 25 in.
Wedge Height 8 in. 8 in. 8 in.
Cycle Time
Forward 8 Seconds* 8 Seconds* 7 Seconds*
Reverse 5 Seconds* 5 Seconds* 4 Seconds*
Wheels 16 x 4.8 x 8 in. 16 x 4.8 x 8 in. 16 x 4.8 x 8 in.
Hydraulic Capacity Approx. 4 Gallons Approx. 4 Gallons Approx. 5 Gallons
Height (Horizontal / Vertical Position) 41.5 / 71 in. 41.5 / 71 in. 41.5 / 71 in.
Length 87 / 84 in. 87 / 84 in. 87 / 84 in.
Width 41 in. 41 in. 41 in.
Net Weight 474 lbs 512 lbs 549 lbs
*Tonnage and cycle times may vary dependent upon mechanical and environmental conditions.
Assembly
Tools and Supplies Needed:

24mm Wrench

18mm Wrench
 19mm Wrench
 Pliers

Soft Faced Hammer

16mm Wrench
 17mm Wrench
 13mm Wrench

12mm Wrench

8mm or Flat Philips Screwdriver
 Adjustable Wrench

14mm Wrench

1/2" Wrench

3mm Allen Wrench
 Thread Locking Compound

27mm wrench or 1-1/16" wrench or adjustable wrench
