DR Power 22-Ton (July 2013 - Present) User Manual
Page 7
CONTACT US AT www.DRpower.com 7
Horizontal
Beam Lock
Jack Stand
Tongue
Control Handle
Splitting Wedge
Log Dislodger
Cylinder
End Plate
Log Tray
Vertical
Beam Lock
Chapter 2: Assembly and Setting Up The DR VERTICAL/HORIZONTAL LOG SPLITTER
It may be helpful to familiarize yourself with the controls and features of your DR VERTICAL/HORIZONTAL LOG SPLITTER as
shown in Figure 1 before beginning these procedures. If you have any questions at all, please feel free to contact us at
www.DRpower.com.
DR VERTICAL/HORIZONTAL LOG SPLITTER Controls and Features
(Figure 1)
