Before You Begin...
Customer Service Information
all specifications subject to change without notice. dacor assumes no liability for changes to specifications.
Important:
installer: • In the interest of safety and to minimize problems, read these installation instructions completely and care-
fully before you begin the installation process. Leave these installation instructions with the customer.
customer:
• Keep these installation instructions for future reference and the local electrical inspector’s use.
© 2008 Dacor, all rights reserved.
california proposiTion 65 warning
The burning of gas cooking fuel generates some by-products
that are on the list of substances which are known by the State
of California to cause cancer or reproductive harm. California
law requires businesses to warn customers of potential
exposure to such substances. To minimize exposure to these
substances, always operate this unit according to the use
and care manual, ensuring you provide good ventilation when
cooking with gas.
If You Need Help...
If you have questions or problems with installation, contact
your Dacor ® dealer or the Dacor Customer Service Team.
For repairs to Dacor appliances under warranty call the
Dacor Distinctive Service line. Whenever you call, have
the model and serial number of the appliance ready. The
model and serial number are printed on the product data
label on the back of the unit. The product data label also
specifies the power supply requirements.
dacor customer service
Phone: (800) 793-0093. (U.S.A. and Canada)
Monday - Friday 6:00
a
.
m
. to 5:00
p
.
m
. Pacific Time
Web site: www.Dacor.com
dacor distinctive service (repairs under warranty only)
Phone: (877) 337-3226 (U.S.A. and Canada)
Monday - Friday 6:00
a
.
m
. to 4:00
p
.
m
. Pacific Time
Model Identification
OB36 36-inches wide, no side burner, three (3)
U shaped burners in main compartment
OBS36 36-inches wide, no side burner, two (2)
U shaped burners and one (1) sear burner in
main compartment
OB52 52-inches wide with side burner, three (3)
U shaped burners in main compartment
OBS52 52-inches wide with side burner, two (2)
U shaped burners and one (1) sear burner in
main compartment
OBSB162 Stand alone side burner
Model numbers with “NG” are equipped (only) for use with
natural gas. Model numbers with “LP” are equipped (only)
for use with liquid petroleum (propane).
installation instructions .................................................. 10
Preparing for Installation ................................................ 10
Cabinet Installation ......................................................... 12
Cart Installation .............................................................. 12
Connecting the Gas ....................................................... 14
Final Assembly and Test ................................................ 15
Verifying Proper Operation ............................................. 17
wiring diagrams .............................................................. 18
notes................................................................................. 20
Table of Contents
Before You Begin... ........................................................... 1
important safety instructions .......................................... 1
Important Information About Safety Instructions .............. 1
General Safety Precautions ............................................. 2
planning the installation ................................................... 4
Product Dimensions ......................................................... 4
Location Planning - General ............................................ 6
Location Planning - Enclosed Cabinets ........................... 7
Location Planning - Cart Installations .............................. 9
