Dacor OB52 - Manual (Page 31)

2
A mINImUm clearance of 1/4 inch (6 mm) must be •
maintained, inside the base enclosure below the
countertop material, from all vertical surfaces on the
sides of the appliance, except on model OBSB162.
On model OBSB162 a minimum clearance of 1/4 inch
(6 mm) must be maintained in back and 1/16 inch
on the sides.
A MINIMUM clearance of 3/4 inch (19 mm) must be
•
maintained, from the bottom of the control panel to
any material for ventilation purposes. failure to do
so will block air flow through the outdoor grill and
may cause carbon monoxide poisoning or improper
operation.
Keep items that could explode, such as aerosol cans
•
away from the outdoor grill and burners. Do not
store flammable or explosive materials in adjacent
cabinets or areas.
Use only the factory supplied gas regulator or a
•
Dacor approved replacement.
On models OB52 and OBS52 equipped for use with
•
a LP tank, use only a two stage regulator on the gas
supply line.
ImPortant
• : the outdoor grill and rotisserie motor
are both equipped with a three prong grounding
electrical plug to minimize the possibility of an
electric shock hazard from this appliance. they must
be plugged into a grounded, electrical outlet that
meets local code for use with outdoor appliances. It
is the responsibility of the customer to make sure
the correct type of outlet, meeting local code, is
installed. Do not under any circumstances:
Cut or remove ◊
the third (ground)
prong from the
power cord.
Use an adapter
◊
plug.
Use a power cord
◊
that is frayed or
damaged.
If using an extension •
cord, use only a
grounded cord
approved for use outdoors. Use a cord that is as
short as possible. Avoid routing it through wet areas.
Important Safety Instructions
If the information in this manual is not followed •
exactly, a fire or explosion may result causing
property damage, personal injury or death.
If you receive a damaged product, immediately
•
contact your dealer or builder. Do not install or
operate an appliance that has been damaged or
dropped. Do not operate the rotisserie motor if it is
damaged or malfunctioning.
make sure that this appliance has been properly
•
installed by a qualified installer according to the
accompanying installation instructions. have the
installer show you the location of the gas shut-off
valve and the electrical outlet so that you know
where and how to turn off the gas supply and
disconnect power to the appliance.
Use only the type of gas specified on the product
•
data label on the back of the unit.
To prevent hazardous combustion by-products from
•
being drawn inside the house or building, keep the
appliance clear of fresh air inlets.
Do not repair or replace any part of this appliance
•
unless specifically recommended in the literature
accompanying it. All other service should be done by
a qualified technician. Contact the Dacor Customer
Service team for examination, repair or adjustment.
Before performing any type of cleaning or service, or
•
moving the appliance, make sure that the gas supply
is turned off and the power plug is disconnected
from the electrical outlet.
Do not install or use this appliance under
•
unprotected overhead combustible materials.
In the event of a power failure, use only the Dacor
•
supplied match light tool or a long stemmed match.
A mINImUm clearance of 10 inches (254 mm) must
•
be maintained, above the countertop material, from
all combustible vertical materials on the sides and
behind the outdoor grill chassis and canopy.
On all models except OBSB162, a mINImUm
•
clearance of 1 1/4 inches (32 mm) must be
maintained, above the countertop material, from all
non-combustible vertical materials on the sides and
behind the outdoor grill chassis and canopy.
On model OBSB162, a mINImUm clearance of 2
•
inches (51 mm) must be maintained, above the
countertop material, from all non-combustible
vertical materials on the sides and behind the
outdoor grill chassis and canopy.
warning warning
three prong
grounding plug
Grounded
electrical outlet
for outdoor use
General Safety Precautions
To reduce the risk of fire, electric shock, serious injury or death, follow basic safety precautions, including the
following:
