12
Cart Installation
warning
Attach the appliance to the cart with all of the supplied •
bolts before use.
All gas and electrical connections should be made
•
after the grill is installed and bolted to the cart.
To avoid an explosion hazard, do not connect the cart
•
or appliance(s) to electrical power until after the gas
supply system has been checked for leaks.
iMporTanT
To prevent damage to the gas regulator, install the
regulator only after the appliance is mounted in its
permanent position on the cart.
Remove the cart from the shipping pallet before instal- 1.
lation. The Dacor cart ships assembled ready for
installation of the outdoor grill. Set the cart in an open
location and lock the wheels on the cart to minimize
movement.
Remove the drawers.
2.
With at least one person on each side, lift the appliance 3.
up and lower it onto the cart. As you lower it onto the
cart slide the electrical cord into the utility cut-out.
Center the unit on the cart, making sure to line up the 4.
threaded mounting holes under the bottom of the grill
with the holes in the top of the cart.
Thread all of the supplied bolts into the bottom of the
5.
outdoor grill from inside the cart. Tighten the bolts into
place.
Utility cutout
Rotating wheel
Locking
wheel Locking wheel
Tank shelf
Insert power cord
into utility cutout
36-Inch cart Shown
Cabinet Installation
warning
To avoid an explosion hazard, do not connect the cart or
appliance(s) to electrical power until after the gas supply
system has been checked for leaks.
iMporTanT
To prevent damage to the gas regulator, install the
regulator only after the appliance is mounted in its
permanent position in the enclosure.
With at least one person on each side of the unit, lift •
it up and lower it into the cabinet cutout. As you lower
it into the cutout slide the electrical cord into the utility
cutout.
Installation Instructions
oBsB162 oB36 or
oBs36
oB52 or
oBs52
Insert power cord
into utility cutout
Insert power cord
into utility cutout
