Comtech EF Data RAP-100 - Manual (Page 31)

ODU Operation RAP-100 Remote Access Panel
3–14 Rev. 1
3.2.51 (ODU,ENABLE,1:1,CSAT#1,ALARMS,STORED) VIEW
(ODU,ENABLE,1:1,CSAT#2,ALARMS,STORED) VIEW
(ODU,ENABLE,STAND-ALONE,ALARMS,STORED) VIEW
LOG 02:11/13/99 10:42:47
OK- REF LOCK (UP/DWN)
The operator uses the UP/DOWN arrow keys to sequentially view the individual entries
in the Stored Events Log, then press CLEAR to exit the window.
3.2.52 (ODU,ENABLE,1:1,CSAT#1,ALARMS,STORED) CLEAR ALL
(ODU,ENABLE,1:1,CSAT#2,ALARMS,STORED) CLEAR ALL
(ODU,ENABLE,STAND-ALONE,ALARMS,STORED) CLEAR ALL
PRESS ENTER TO
CLEAR THE EVENTS LOG
The operator the ENTER key to clear the event log, else press CLEAR to exit the
window.
