RAP-100 Remote Access Panel ODU Operation
Rev. 1 3–7
3.2.21 (ODU,ENABLE,1:1,CSAT#1,CONFIG,RECEIVER) ATTEN (Attenuation)
(ODU,ENABLE,1:1,CSAT#2,CONFIG,RECEIVER) ATTEN (Attenuation)
(ODU,ENABLE,STAND-ALONE,CONFIG,RECEIVER) ATTEN (Attenuation)
EDIT ODU RX ATTENUATION:
15.00 dB (PRESS ENTER)
The user is prompted to edit the receive attentuation. This is accomplished by selecting
the digit to be edited, using the LEFT/RIGHT arrow keys. The value of the digit is then
changed using the UP/DOWN arrow keys. The user then presses ENTER.
3.2.22 (ODU,ENABLE,1:1,CSAT#1,CONFIG,RECEIVER) MUTE
(ODU,ENABLE,1:1,CSAT#2,CONFIG,RECEIVER) MUTE
(ODU,ENABLE,STAND-ALONE,CONFIG,RECEIVER) MUTE
SELECT RX MUTE STATE:
MUTED UNMUTED (ENTER)
The user is prompted to select either MUTED or UNMUTED, using the LEFT/RIGHT
arrow keys, then to press ENTER.
3.2.23 (ODU,ENABLE,1:1,CSAT#1,CONFIG,RECEIVER) SLOPE
(ODU,ENABLE,1:1,CSAT#2,CONFIG,RECEIVER) SLOPE
(ODU,ENABLE,STAND-ALONE,CONFIG,RECEIVER) SLOPE
SELECT RX SLOPE MODE:
CALIBRATED MANUAL (ENT)
The user is prompted to select either CALIBRATED or MANUAL, using the
LEFT/RIGHT arrow keys, then to press ENTER.
3.2.24 (ODU,ENABLE,1:1,CSAT#1,CONFIG,RECEIVER,SLOPE) MANUAL
(ODU,ENABLE,1:1,CSAT#2,CONFIG,RECEIVER,SLOPE) MANUAL
(ODU,ENABLE,STAND-ALONE,CONFIG,RECEIVER,SLOPE) MANUAL
EDIT ODU RX SLOPE:
0.0 (PRESS ENTER)
If MANUAL mode is selected, the user is prompted to edit the receive slope setting. This
is accomplished using the UP/DOWN arrow keys. The user then presses ENTER.
