ODU Operation RAP-100 Remote Access Panel
3–12 Rev. 1
3.2.42 (ODU,ENABLE,1:1,CSAT#1) MONITOR
(ODU,ENABLE,1:1,CSAT#2) MONITOR
(ODU,ENABLE,STAND-ALONE) MONITOR
MONITOR: TX RX MISC
PWR SUPP1 PWR SUPP2
The operator uses this menu item to select enter 1 of 5 ‘Monitor Windows’. Use the
LEFT/RIGHT arrow keys, then press ENTER.
3.2.43 (ODU,ENABLE,1:1,CSAT#1,MONITOR) TX (Transmitter)
(ODU,ENABLE,1:1,CSAT#2,MONITOR) TX (Transmitter)
(ODU,ENABLE,STAND-ALONE,MONITOR) TX (Transmitter)
TX: SYNTUNE=04.8 PWR=040
IFLO = 10.7 TEMP= 27C
This window provides the Tx Synthesizer and IFLO tuning voltages, the RF Output
Power in dBm and the Transmitter temperature, press ENTER.
3.2.44 (ODU,ENABLE,1:1,CSAT#1,MONITOR) RX (Receiver)
(ODU,ENABLE,1:1,CSAT#2,MONITOR) RX (Receiver)
(ODU,ENABLE,STAND-ALONE,MONITOR) RX (Receiver)
RX: SYNTH TUNE = 03.1
IFLO = 10.9 TEMP= 28C
This window provides the Rx Synthesizer and IFLO tuning voltages and the Receiver
temperature, press ENTER.
3.2.45 (ODU,ENABLE,1:1,CSAT#1,MONITOR) MISC
(ODU,ENABLE,1:1,CSAT#2,MONITOR) MISC
(ODU,ENABLE,STAND-ALONE,MONITOR) MISC
MISC: REF TUNE = 03.0
LNA=000. mA FAN=568 mA
This window provides the Internal Reference Oscillator tuning voltages, the LNA Current
in milliamps and the Fan Current in milliamps, press ENTER.
3.2.46 (ODU,ENABLE,1:1,CSAT#1,MONITOR) PWR SUPP1
(ODU,ENABLE,1:1,CSAT#2,MONITOR) PWR SUPP1
(ODU,ENABLE,STAND-ALONE,MONITOR) PWR SUPP1
PS: 24V=23.8 20V=22.6
12V=13.0 10V=10.1
This window provides a monitor for four of the six internal power supplies, press
ENTER.
