ODU Operation RAP-100 Remote Access Panel
3–6 Rev. 1
3.2.17 (ODU,ENABLE,1:1,CSAT#1,CONFIG,TRANSMITTER) SLOPE
(ODU,ENABLE,1:1,CSAT#2,CONFIG,TRANSMITTER) SLOPE
(ODU,ENABLE,STAND-ALONE,CONFIG,TRANSMITTER) SLOPE
SELECT TX SLOPE MODE:
CALIBRATED MANUAL (ENT)
The user is prompted to select either CALIBRATED or MANUAL, using the
LEFT/RIGHT arrow keys, then to press ENTER.
3.2.18 (ODU,ENABLE,1:1,CSAT#1,CONFIG,TRANSMITTER,SLOPE) MANUAL
(ODU,ENABLE,1:1,CSAT#2,CONFIG,TRANSMITTER,SLOPE) MANUAL
(ODU,ENABLE,STAND-ALONE,CONFIG,TRANSMITTER,SLOPE) MANUAL
EDIT ODU TX SLOPE:
0.0 (PRESS ENTER)
If MANUAL mode is selected, the user is prompted to edit the transmit slope setting.
This is accomplished using the UP/DOWN arrow keys. The user then presses ENTER.
3.2.19 (ODU,ENABLE,1:1,CSAT#1,CONFIG) RECEIVER
(ODU,ENABLE,1:1,CSAT#2,CONFIG) RECEIVER
(ODU,ENABLE,STAND-ALONE,CONFIG) RECEIVER
ODU RX: FREQUENCY ATTEN
MUTE SLOPE LNA
This menu item is used to select which ODU Receivter parameter is to be modified. Use
the LEFT/RIGHT arrow keys, then press ENTER.
3.2.20 (ODU,ENABLE,1:1,CSAT#1,CONFIG,RECEIVER) FREQUENCY
(ODU,ENABLE,1:1,CSAT#2,CONFIG,RECEIVER) FREQUENCY
(ODU,ENABLE,STAND-ALONE,CONFIG,RECEIVER) FREQUENCY
EDIT ODU RX FREQUENCY:
3912.5 MHz (PRESS ENT)
The user is prompted to edit the receive frequency. This is accomplished by selecting the
digit to be edited, using the LEFT/RIGHT arrow keys. The value of the digit is then
changed using the UP/DOWN arrow keys. The user then press ENTER.
