DD2401 Satellite Demodulator Electrical Interfaces
MN-DD2401 - Rev. G 5- 5
5.7 Remote Addresses
The demodulator supports up to 16 different remote addresses. Refer to Tables 5-4 and 5-5 for
S1 DIP Switch settings. The S1 DIP switch is located on the main board. Refer to diagram 5-3
For dip switch diagram
Table 5-4. S1 DIP Switch
Position
1
Position
2
Position
3
Position
4
Address in
Decimal
off off off off 32 (default)
on off off off 33
off on off off 34
on on off off 35
off off on off 36
on off on off 37
off on on off 38
on on on off 39
off off off on 40
on off off on 41
off on off on 42
on on off on 43
off off on on 44
on off on on 45
off on on on 46
on on on on 47
