System and Design Manual, Revision 2
Operator Functions 5–19
Channel Status
Color Text Description
Green CIP Channel is currently in use (active call)
Blue Idle Channel has no CIP, but fully functional
Red Fault Channel modem is not in a functional state
Yellow Warning Channel is reporting a modem fault, but is still in a functional state
Gray Disabled Channel has been disabled by operator
Node Status
Color Text Description
Green Online-CIP Node is communicating with NMS, is fully functional, at least one
channel with CIP
Online Node is fully functional, but has no channels with CIP
Red Fault Node modem is not in a functional state, or node has all enabled
channels faulted
Warning Node has some, but not all, channels faulted
Blue Disabled Node has been disabled by operator
Site Status
Color Text Description
Green Online-CIP Site has all associated nodes online, at least one node online-CIP
Online SITE has all associated nodes online, but none with CIP
Red Fault site has all nodes faulted
Yellow Warning Site has some, but not all, nodes faulted, or site has nodes
reporting a warning status
Blue Disabled All nodes at site are disabled
