Comtech EF Data MIDAS 4 System and Design - Manual (Page 121)

System and Design Manual, Revision 2
Traffic Node 6–23
7 7 0 0 / / 1 1 4 4 0 0 M M H H z z I I F F
I I n n t t e e r r f f a a c c e e
The traffic node connects to the RF equipment via the IF interface, whose
characteristics are as follows:
Operating IF Range 50 to 180 MHz
Characteristic Impedance 75
Ω
Transmit Level:
SNM-1000, SNM-1010
SDM-100, SDM-300/300A
CDM-550, CDM-600, CiM-550
-30 to -5 dBm
-30 to -5 dBm
-20 to 0 dBm
Receive Level (at Modem):
SNM-1000, SNM-1010
SDM-100, SDM-300/300A
CDM-550, CDM-600, CiM-550
-55 to -30 dBm
-55 to -30 dBm
-60 to –30 dBm
L L - - B B a a n n d d R R F F I I n n t t e e r r f f a a c c e e
Operating RF Range
Transmit Level:
SNM-1010L
Receive Level (at Modem):
SNM-1010L
950 to 1750 MHz
-40 to 0 dBm
-135 dBm + 10log(symbol rate)
to –85 dBm +10log (symbol rate)
