System and Design Manual, Revision 2
6–10 Traffic
Node
C
C
D
D
M
M
-
-
6
6
0
0
0
0
D
D
a
a
t
t
a
a
/
/
S
S
y
y
m
m
b
b
o
o
l
l
R
R
a
a
t
t
e
e
CDM-600
2,400
20,000,000
Modulation
Encoding Type
Data Rates (bps)
Symbol Rates (sym/s)
Type
Minimum
Maximum
Minimum
Maximum
BPSK 1/2
Viterbi
2,400
5,000,000
4,800
10,000,000
{O}QPSK 1/2 Viterbi
4,800
10,000,000
4,800
10,000,000
{O}QPSK 3/4 Viterbi
7,200
15,000,000
4,800
10,000,000
{O}QPSK 7/8 Viterbi
8,400
17,500,000
4,800
10,000,000
BPSK 1/1
Uncoded
4,800
10,000,000
4,800
10,000,000
{O}QPSK 1/1 Uncoded
9,600
20,000,000
4,800
10,000,000
BPSK 1/2
Sequential
2,400
1,024,000
4,800
2,048,000
QPSK 1/2
Sequential
4,800
2,048,000
4,800
2,048,000
QPSK 3/4
Sequential
7,200
2,048,000
4,800
1,365,333
QPSK 7/8
Sequential
8,400
2,048,000
4,800
1,170,286
BPSK 1/2
Viterbi and Reed-Solomon
2,400
4,545,454
4,800
10,000,000
{O}QPSK 1/2 Viterbi and Reed-Solomon
4,800
9,090,909
4,800
10,000,000
{O}QPSK 3/4 Viterbi and Reed-Solomon
7,200
13,636,363
4,800
10,000,000
{O}QPSK 7/8 Viterbi and Reed-Solomon
8,400
15,909,090
4,800
10,000,000
16QAM 3/4
Viterbi and Reed-Solomon
14,400
18,000,000
4,800
6,600,000
16QAM 7/8
Viterbi and Reed-Solomon
16,800
18,000,000
4,800
5,657,143
BPSK 1/2
Sequential and Reed-Solomon
2,400
1,024,000
4,800
2,252,800
QPSK 1/2
Sequential and Reed-Solomon
4,800
2,048,000
4,800
2,252,800
QPSK 3/4
Sequential and Reed-Solomon
7,200
2,048,000
4,800
1,501,867
QPSK 7/8
Sequential and Reed-Solomon
8,400
2,048,000
4,800
1,287,314
8PSK 2/3
TCM + Reed-Solomon
9,600
18,181,818
4,800
10,000,000
8PSK 2/3
TCM No Reed-Solomon
9,600
20,000,000
4,800
10,000,000
BPSK 21/44
Turbo
4,800
3,200,000
4,800
6,704,762
BPSK 5/16
Turbo
4,800
2,048,000
4,800
6,553,600
{O}QPSK 3/4 Turbo
7,200
5,000,000
4,800
3,333,333
8PSK 3/4
Turbo
10,800
5,000,000
4,800
2,222,222
16QAM 3/4
Turbo
14,400
5,000,000
4,800
1,666,667
Output power
0 to -20 dBm, 0.1 dB steps
Clocking options
Internal, Ext Ref, Tx Terrrestrial, and Sat Loop Timing
Doppler Buffer
64 to 262144 bits, in 16 bit increments
